Overview

The RXR-M120D is a medium-sized tracked oil-powered fire-fighting robot. It is powered by a diesel engine and uses a closed hydraulic system to drive the ASV rubber tracks for high-speed movement. It is equipped with a high-flow fire cannon that can spray 120 liters per second and carries various detection and monitoring sensors to conduct remote real-time monitoring of the fire scene and extinguish the fire.
This product features remote control, panoramic display and other functions, and has excellent off-road performance. It is equipped with an integrated hydraulic brake system, which can effectively apply the parking brake and prevent the whole machine from rolling away.

Scope of application

Rescue operations for large-scale fires in petroleum and chemical enterprises:

Places prone to collapse, such as tunnels and subways, require entry for firefighting and rescue.

Rescue operations in environments with potential explosive gas or liquid leaks.

 Rescue operations in environments with thick smoke or toxic gases.

Firefighting and rescue operations in close proximity, where personnel are at risk of injury.

Feaures

High flow rate, long range
The water flow rate of the fire monitor can reach 120L/s, with a water range exceeding 95m and a foam range exceeding 90m.
2. High traction
It is driven by a hydraulic motor for track movement, with a diesel engine power of nearly 30KW and a horizontal traction force of up to 8KN.
3. High-integration detection and monitoring (optional)
It can measure 14 types of gases, including temperature, humidity, CO2, CH4, CO, H2S, O2, H2, NH3, Cl2, SO2, NO2, C3H8 (propane), C2H4O (acetaldehyde), C2H2 (acetylene), and VOC (optional).
4.  High speed
The straight-line walking speed is greater than 3.6 m/s, and it has remote control stepless speed change.
5. High mobility
It is suitable for various road conditions, with an obstacle-crossing height of up to 300mm and a climbing slope of up to 25° (46.6%).
6. High-intelligence functions (4 major functions available as options)
It features voice control, two-way voice communication, redundant communication, and access to a robot networked cloud platform, among other intelligent functions.
7. Cloud Platform (Optional)
By accessing the robot networked cloud platform, equipment information, gas and video information can be remotely monitored, and statistical analysis can be conducted. The validity period of the equipment can be automatically verified, and automatic reminders for expired equipment information statistics can be provided. This enables comprehensive management applications to ensure the timeliness of the equipment.
8. Multiple hydraulic output power interfaces (optional)
Reserve hydraulic output interface, with a pressure of 16 MPa and a flow rate up to 25 L/min, to meet the requirements of hydraulic demolition tools, hydraulic generators, hydraulic high-pressure water pumps, hydraulic welding machines and other hydraulic tools and equipment.

Technical parameters:

Wide applicability
2.  Strong adaptability
3. Powerful performance
4. Rapid Implementation
5. Fully Automated
Company Introduction

Beijing Topsky Intelligent equipment Group Co.,Ltd.. (stock code: 836307) was founded in 2003, committed to making the world safer with innovative equipment, and determined to become a continuous leader in global high-end safety equipment.
Our company has independent R&D and technology promotion capabilities, and has one R&D and production building. Headquartered in Jinqiao Industrial Base, Zhongguancun High-tech Park, it is a national high-tech enterprise with a registered capital of RMB 46,514,300. Our company has independent R&D and manufacturing capabilities. Located in Beijing Economic Development Zone, the 3-story R&D building covers an area of 1,500 square meters, the production building is 1,800 square meters, and the third-phase production building is nearly 3,000 square meters under construction.
Our innovative technologies, services and systems are dedicated to serving the firefighting, law enforcement agencies, safety supervision bureaus, coal mines, petrochemicals, and armed  in many fields. It involves the research and development of high-end equipment such as drones, robots, unmanned ships, special equipment, emergency rescue equipment, law enforcement equipment, and coal mine equipment.
    So far, many products have been exported to more than 10 countries.
